Compression Z2+2 Geometry
The verified positive/negative Z2+2 arrangement identifies this exact SM01 configuration as a compression-style spiral tool.
ITA Tools Solid Carbide Compression Router Bit 1/2". × 1". 2-Tooth+2 Right-Hand
CA$139.00
Out of stock
SKU
SM01.13.254.762.13R
Product Type
Solid-carbide compression spiral finishing router bit
Series
SM01
Cutting Diameter
1/2 in. (12.70 mm)
Working Length
1 in. (25.40 mm)
Compression Edge
15/32 in. (approximately 11.91 mm)
Overall Length
3 in. (76.20 mm)
Shank
1/2 in. (12.70 mm)
Cutting Geometry
Z2+2 · positive/negative · RH
SM01
Z2+2
Compression Router
ITA TOOLS catalogue index SM01.13.254.762.13R is a right-hand VHM solid-carbide compression spiral finishing router bit with a 1/2 in. (12.70 mm) cutting diameter, 1 in. (25.40 mm) working length, 15/32 in. (approximately 11.91 mm) compression edge, 3 in. (76.20 mm) overall length, 1/2 in. (12.70 mm) shank, and Z2+2 positive/negative geometry.
1/2 in.Cutting Diameter
1 in.Working Length
Z2+2Compression Geometry
Solid CarbideCutting Material
Solid-Carbide Compression Router Bit
An SM01-series VHM compression spiral finishing router bit for the verified plywood, raw particleboard, raw MDF, softwood, and hardwood applications.
ITA TOOLSSM01RH · Z2+2SM01.13.254.762.13R
Confirm the 1/2-inch shank, required clamping length, RH rotation, holder rating, machine limits, and exact workpiece material before use. The official catalogue index must remain unchanged.
Main Product Description
ITA TOOLS SM01.13.254.762.13R is the exact SM01-series VHM solid-carbide compression spiral finishing router bit. Its verified dimensions are a 1/2 in. (12.70 mm) cutting diameter, 1 in. (25.40 mm) working length, and 15/32 in. (approximately 11.91 mm) compression edge.
The verified configuration has a 3 in. (76.20 mm) overall length, 1/2 in. (12.70 mm) shank, right-hand rotation, and Z2+2 positive/negative compression geometry.
The published workpiece-material list covers plywood, raw particleboard, raw MDF, softwood, and hardwood. The tool is identified for finishing operations.
Technical Specifications
SM01 · SM01.13.254.762.13R
- ITA TOOLS
- Solid-Carbide Compression Spiral Finishing Router Bit
- SM01.13.254.762.13R
- SM01
- VHM / Solid Carbide
- 1/2 in. (12.70 mm)
- 1 in. (25.40 mm)
- 15/32 in. (approximately 11.91 mm)
- 3 in. (76.20 mm)
- 1/2 in. (12.70 mm)
- Z2+2 · Positive / Negative Compression
- RH
- Plywood, Raw Particleboard, Raw MDF, Softwood and Hardwood
- Confirm the 1/2-inch shank, required clamping length, RH rotation, holder rating, machine limits, and exact workpiece material before use. The official catalogue index must remain unchanged.
Best Fit Applications
Plywood Routing
Raw Particleboard Routing
Raw MDF Routing
Softwood Routing
Hardwood Routing
Product Highlights
Solid-Carbide Construction
The exact product construction is VHM solid carbide and is routed to Titan’s approved solid-carbide material image.
Exact Imperial Configuration
The catalogue configuration combines a 1/2-inch diameter, 1-inch working length, 15/32-inch compression edge, 3-inch overall length, and 1/2-inch shank.
Compatibility & Selection Notes
Verify the exact catalogue index SM01.13.254.762.13R, 1/2-inch shank, required clamping length, RH rotation, holder compatibility, machine limits, and workpiece material before selection. Do not derive spindle speed, feed speed, chip load, depth of cut, or toolpath settings from the catalogue index. Follow the machine, holder, and official ITA TOOLS documentation.
Exact SM01 Compression Configuration
ITA TOOLS catalogue index SM01.13.254.762.13R identifies the exact 1/2-inch SM01-series solid-carbide compression router bit with a 1-inch working length, Z2+2 positive/negative geometry, and right-hand rotation.
The catalogue index, series, dimensions, rotation, cutting material, geometry, and published material applications must remain separate from neighbouring SM01 variants.
