Working geometry
The locating point helps position the hole before the cutting edges reach the surface.
CMT 311.060.41 – Drill Bit D6xL70mm Brad Point RH XTreme
CA$28.95
In stock
SKU
311.060.41
Product Type
Carbide-Head Dowel Boring Bit
Tool Material
Carbide
Cutting Diameter
6 mm
Cutting Length
35 mm
Shank Diameter
10 mm
Overall Length
70 mm
Shank Length
30 mm
Flutes
2
Spurs
2
Rotation
Right Hand
Body Material
Steel
Cutting Portion Material
Solid Carbide
Carbide-Head Dowel Boring Bit
CMT Utensili
311.060.41
Designed to bore holes for dowels and joinery.
6 mmCutting Diameter
35 mmCutting Length
10 mmShank Diameter
70 mmOverall Length
Carbide-Head Dowel Boring Bit
Carbide cutting edges provide a hard, wear-resistant working surface.
CarbideRight HandSKU 311.060.41
Choose a holder or collet for the 10 mm shank and check the available tool clearance.
Main Product Description
This CMT Utensili carbide-head dowel boring bit is designed to bore holes for dowels and joinery. It is suitable for solid wood, wood composites, plastics and laminated materials.
The locating point helps position the hole before the cutting edges reach the surface. Set the drilling depth to suit the joint and the thickness of the workpiece. Carbide cutting edges provide a hard, wear-resistant working surface.
The 6 mm cutting diameter and 35 mm cutting length define the working section of this version. Its 10 mm shank fits a holder or collet matched to that diameter. This version is for right-hand rotation.
Technical Specifications
311.060.41 · Carbide-Head Dowel Boring Bit
- CMT Utensili
- 311.060.41
- Carbide-Head Dowel Boring Bit
- 311
- Carbide
- 6 mm
- 35 mm
- 10 mm
- 70 mm
- 30 mm
- 2
- 2
- Right Hand
- Steel
- Solid Carbide
- PTFE on spiral portion
Tool Configuration
blind-hole boring
Product Highlights
Cutting material
Carbide cutting edges provide a hard, wear-resistant working surface.
This version
The 6 mm cutting diameter and 35 mm cutting length define the working section of this version. Its 10 mm shank fits a holder or collet matched to that diameter. This version is for right-hand rotation.
Compatibility & Installation Notes
Match the tool and holder to the machine, workpiece and intended operation before use.
Carbide-Head Dowel Boring Bit
CMT Utensili 311.060.41 is designed to bore holes for dowels and joinery. It is suitable for solid wood, wood composites, plastics and laminated materials.
The locating point helps position the hole before the cutting edges reach the surface. Set the drilling depth to suit the joint and the thickness of the workpiece. Carbide cutting edges provide a hard, wear-resistant working surface.
The 6 mm cutting diameter and 35 mm cutting length define the working section of this version. Its 10 mm shank fits a holder or collet matched to that diameter. This version is for right-hand rotation.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
