Exact 6 mm LH Variant
Item Code 311.060.42 combines a 6 mm diameter, 35 mm cutting length, 70 mm overall length, 10 × 30 mm shank, and verified left-hand rotation.
CMT Orange Tools Brad-Point Dowel Drill 6mm x 35mm Cutting Length x 70mm Overall Length, 10x30mm Shank, Left-Hand
CA$999.99
In stock
SKU
311.060.42
Product Type
XTREME left-hand brad-point dowel drill
Family / Series
CMT 311.41/42 XTREME Long-Life
Drill Diameter
6 mm
Cutting / Overall
35 mm cutting length · 70 mm overall length
Shank
10 × 30 mm parallel shank with driving flat
Geometry
LH · Z2 cutting edges · V2 negative spurs · two spiral flutes
Cutting Material
Extra-fine micrograin carbide
Applications
Blind holes in solid wood,composites,chipboard,MDF,laminates,and plastics
XTREME Z2 · V2
Brad-Point Dowel Drill
XTREME Dowel Drill
CMT 311.060.42 is the exact 6 mm left-hand variant in the 311.41/42 XTREME long-life dowel-drill family. It combines a 35 mm cutting length, 70 mm overall length, 10 × 30 mm parallel shank with driving flat, two cutting edges, two curved negative spurs, two spiral flutes, and an extra-fine micrograin carbide cutting section for blind-hole drilling in solid wood, wood composites, laminates, and plastics.
6 mmDrill Diameter (D)
35 mmCutting Length (I)
70 mmOverall Length (L)
LH · Z2/V2Rotation & Geometry
XTREME Dowel Drill
A left-hand industrial blind-hole dowel drill with an extra-fine micrograin carbide cutting and spiral section, centre point, two cutting edges, two spiral flutes, two curved negatively ground spurs, and black/orange P.T.F.E. surface coating.
CMT Orange ToolsXTREME Series10 × 30 mm ShankSKU 311.060.42
For compatible high-speed boring machines, point-to-point machines, CNC routers, chucks, and adaptors accepting the verified 10 × 30 mm shank. Confirm left-hand rotation, shank seating, driving-flat engagement, axial adjustment, workholding, clearance, and machine/tool speed limits before operation.
Main Product Description
CMT 311.060.42 is the exact left-hand 6 mm item in the official 311.41/42 long-life dowel-drill family. The verified variation row specifies a 6 mm diameter, 35 mm cutting length, 70 mm overall length, 10 × 30 mm shank, and LH rotation.
The XTREME design uses a premium extra-fine micrograin carbide cutting and spiral section with a centre point, two cutting edges, two spiral flutes, and two curved negative spurs. The geometry is intended to support accurate blind-hole entry, clean rim formation, chip evacuation, long cutting life, and repeated resharpening.
A parallel shank with driving flat and axial-adjustment screw supports installation in compatible boring-machine chucks and adaptors. CMT identifies the family for solid wood, wood derivatives, chipboard, laminates, MDF, and plastic materials, including use on high-speed boring machines, point-to-point equipment, and CNC routers.
Technical Specifications
Series 311.41/42 · SKU 311.060.42
- CMT Orange Tools
- Left-hand blind-hole brad-point dowel drill
- 311.060.42
- 311.41/42 — XTREME Long-Life Dowel Drills
- 6 mm
- 35 mm
- 70 mm
- 10 × 30 mm
- LH — left hand
- Z2
- V2 — two curved negatively ground spurs
- Two spiral flutes
- Point Geometry: Centre / brad point · Cutting Material: Extra-fine micrograin carbide · Body / Shank: Premium high-strength steel with driving flat · Surface Coating: Black and orange P.T.F.E. · STIC Screw Reference: 990.003.00 · Optional Weeke Retaining Screw: 990.088.00
- For compatible high-speed boring machines, point-to-point machines, CNC routers, chucks, and adaptors accepting the verified 10 × 30 mm shank. Confirm left-hand rotation, shank seating, driving-flat engagement, axial adjustment, workholding, clearance, and machine/tool speed limits before operation.
Best Fit Applications
Blind Dowel Holes
Solid Wood
Chipboard, MDF & Composites
Laminates & Plastics
Boring, Point-to-Point & CNC Machines
Product Highlights
XTREME Z2 · V2 Geometry
Two cutting edges, two spiral flutes, two curved negative spurs, and a centre point support clean blind-hole drilling and controlled chip evacuation.
Long-Life Carbide Construction
The extra-fine micrograin carbide cutting section supports extended service life, high-speed machine use, accurate centring, and repeated resharpening.
Compatibility & Installation Notes
Confirm exact Item Code 311.060.42, left-hand machine rotation, a compatible 10 × 30 mm boring-bit interface, full driving-flat engagement, and correct axial adjustment before use. Verify chuck or adaptor condition, tool projection, spindle clearance, workholding, and the applicable machine and tool speed limits. STIC screw 990.003.00 is the listed screw reference; 990.088.00 is the optional retaining screw for compatible Weeke machines. Do not substitute the right-hand 311.060.41 variant.
Accurate Blind-Hole Drilling in a Verified 6 mm LH Format
CMT 311.060.42 combines a 6 mm diameter, 35 mm cutting length, 70 mm overall length, 10 × 30 mm shank, left-hand rotation, Z2 cutting edges, V2 spurs, and two spiral flutes.
An extra-fine micrograin carbide cutting section, centre point, P.T.F.E. coating, driving flat, and axial-adjustment system complete the verified XTREME Series 311 configuration.
