Exact 10-Inch 6T Variant
Item Code 236.006.10 combines a 10-inch diameter, 5/8-inch bore, six DP diamond teeth, 0.087-inch kerf, 0.063-inch plate, 12° hook angle, and a 7,600 RPM maximum.
CMT Orange Tools 10" × 5/8" 6-Tooth ® Diamond Fiber Cement Saw Blade
CA$999.99
In stock
SKU
236.006.10
Product Type
ITK Plus® diamond saw blade for fiber cement and plasterboard
Family / Series
CMT 236 ITK Plus® Diamond
Blade Diameter
10 inches
Bore Diameter
5/8 inch
Tooth Count / Grind
6 teeth · DP diamond TCG geometry
Kerf / Plate
0.087-inch kerf · 0.063-inch plate
Hook / Max Speed
12° hook angle · 7,600 RPM maximum
Cutting Material
DP / polycrystalline diamond
Applications
Fiber cement,plasterboard,HardiePlank®,HardiePanel®,Fermacell®,Eternit®,Swisspearl®,and Ivarplank®
ITK Plus® Diamond
Fiber Cement Saw Blade
Diamond Fiber Blade
CMT 236.006.10 is the exact 10-inch variant in the CMT 236 ITK Plus® diamond circular-saw-blade family for ultra-hard materials. It combines a 5/8-inch bore, six DP diamond TCG teeth, a 0.087-inch kerf, 0.063-inch plate thickness, a 12° hook angle, ORANGE SHIELD® coating, and a verified 7,600 RPM maximum for compatible cutting of fiber-cement products and plasterboard.
10 inBlade Diameter (D)
5/8 inBore Diameter (B)
6TTooth Count (Z)
DP TCGDiamond Geometry
Diamond Fiber Blade
An ITK Plus® 10-inch circular saw blade with six DP diamond trapezoidal teeth, a thin steel plate, laser-cut heat-expansion slots, a tensioning ring, precision sharpening, and CMT non-stick ORANGE SHIELD® coating for abrasive sheet materials.
CMT Orange ToolsDP Diamond6T TCGSKU 236.006.10
For compatible portable circular saws, miter saws, radial-arm saws, and stationary table saws accepting a 10-inch blade with a 5/8-inch arbor. Confirm arbor fit, flange condition, guarding, dust collection, material support, and a speed not exceeding 7,600 RPM.
Main Product Description
CMT 236.006.10 is the exact 10-inch item in the official Series 236 ITK Plus® diamond circular-saw-blade family. The verified product data specifies a 10-inch diameter, 5/8-inch bore, six DP diamond teeth, TCG geometry, 0.087-inch kerf, 0.063-inch plate thickness, a 12° hook angle, and a maximum permitted speed of 7,600 RPM.
The low tooth count and diamond cutting system are intended for abrasive fiber-cement boards and plasterboard rather than conventional woodworking finish cuts. CMT identifies the blade for materials including Eternit®, Swisspearl®, Fermacell®, Ivarplank®, HardiePlank®, and HardiePanel® products.
ORANGE SHIELD® non-stick coating helps the plate run cooler, limits residue buildup, and protects against corrosion. Laser-cut heat-expansion slots accommodate operating heat, while dynamic balancing, the visible tensioning ring on the 10-inch plate, and precision tooth finishing support controlled rotation and long service life in abrasive applications.
Technical Specifications
Series 236 · SKU 236.006.10
- CMT Orange Tools
- Diamond circular saw blade for fiber cement and plasterboard
- 236.006.10
- 236 — ITK Plus® Diamond Saw Blades for Ultra-Hard Materials
- 10 in
- 5/8 in
- 6
- DP TCG — diamond trapezoidal grind
- 0.087 in
- 0.063 in
- 12°
- 7,600 RPM
- Active Cutting Material: DP / polycrystalline diamond · Coating: Non-stick ORANGE SHIELD® · Plate Features: Laser-cut heat-expansion slots · Stability Feature: Tensioning ring · Balancing: CMT patented dynamic balancing · Primary Materials: Fiber-cement products and plasterboard
- For compatible portable circular saws, miter saws, radial-arm saws, and stationary table saws accepting a 10-inch blade with a 5/8-inch arbor. Confirm arbor fit, flange condition, guarding, dust collection, material support, and a speed not exceeding 7,600 RPM.
Best Fit Applications
Fiber-Cement Board
Plasterboard
HardiePlank® & HardiePanel®
Fermacell® & Eternit®
Swisspearl® & Ivarplank®
Product Highlights
DP Diamond Cutting System
The six-tooth DP TCG geometry is designed for long service life when cutting abrasive fiber-cement products and plasterboard.
Thin-Plate Stability Features
ORANGE SHIELD® coating, laser-cut heat-expansion slots, dynamic balancing, and a tensioning ring support controlled cutting and plate stability.
Compatibility & Installation Notes
Confirm exact Item Code 236.006.10, a compatible 10-inch saw-blade capacity, and a clean 5/8-inch arbor with properly matched flanges. Verify blade rotation, guarding, workpiece support, dust extraction, and controlled feed before use. Never exceed 7,600 RPM. This is a DP diamond blade for abrasive fiber-cement and plasterboard applications; do not substitute specifications from carbide-only or general-purpose Series 236 references.
Long-Life Fiber-Cement Cutting in a Verified 10-Inch Format
CMT 236.006.10 combines a 10-inch diameter, 5/8-inch bore, six DP diamond TCG teeth, 0.087-inch kerf, 0.063-inch plate, a 12° hook angle, and a 7,600 RPM maximum.
ORANGE SHIELD® coating, laser-cut heat-expansion slots, dynamic balancing, a tensioning ring, and diamond cutting edges complete the verified ITK Plus® Series 236 configuration.
