Exact 10-Inch 96T Variant
Item Code 284.700.10 combines a 10-inch diameter, 5/8-inch bore, 96 TCG teeth, 0.126-inch kerf, 0.098-inch plate, positive 6° hook angle, and a 7,600 RPM maximum.
CMT Orange Tools 10" × 5/8" 96-Tooth Thin Stock Non-Ferrous Metal & PVC Saw Blade
CA$999.99
In stock
SKU
284.700.10
Product Type
Industrial thin-stock non-ferrous metal and PVC circular saw blade
Family / Series
CMT 284.7 Industrial Thin Stock
Blade Diameter
10 inches
Bore Diameter
5/8 inch
Tooth Count / Grind
96 teeth · TCG triple-chip grind
Kerf / Plate
0.126-inch kerf · 0.098-inch plate
Hook / Max Speed
Positive 6° hook angle · 7,600 RPM maximum
Cutting System
Industrial chromium micrograin carbide · ORANGE SHIELD®
Applications
Aluminum,brass,copper,PVC,and thin- or thick-walled non-ferrous extrusions
Industrial Thin Stock
Non-Ferrous & PVC Blade
Thin-Stock NF Blade
CMT 284.700.10 is the exact 10-inch variant in the CMT 284.7 industrial thin-stock non-ferrous-metal and PVC circular-saw-blade family. It combines a 5/8-inch bore, 96-tooth TCG geometry, 0.126-inch kerf, 0.098-inch plate thickness, a positive 6° hook angle, industrial chromium micrograin carbide teeth, ORANGE SHIELD® coating, and a verified maximum speed of 7,600 RPM for compatible heavy-duty cutting of thin-walled and thick-walled non-ferrous extrusions and PVC.
10 inBlade Diameter (D)
5/8 inBore Diameter (B)
96TTooth Count (Z)
TCGTooth Geometry (β)
Thin-Stock NF Blade
An industrial 10-inch circular saw blade with 96 TCG teeth, industrial chromium micrograin carbide, Silver-Copper-Silver tri-metal brazing, laser-cut heat-expansion slots, patented dynamic balancing, a tensioning ring, precision mirror-finish sharpening, and CMT non-stick ORANGE SHIELD® coating.
CMT Orange ToolsIndustrial Carbide96T TCGSKU 284.700.10
For compatible radial-arm saws, miter saws, table saws, and special saws accepting a 10-inch blade with a 5/8-inch arbor. Confirm arbor and flange fit, blade rotation, guarding, secure clamping of extrusions or PVC stock, chip control, and a speed not exceeding 7,600 RPM.
Main Product Description
CMT 284.700.10 is the exact 10-inch item in the official Series 284.7 industrial thin-stock non-ferrous-metal and PVC blade family. The verified live variation row specifies a 10-inch diameter, 5/8-inch bore, 96 teeth, TCG tooth geometry, 0.126-inch kerf, 0.098-inch plate thickness, a positive 6° hook angle, and a maximum permitted speed of 7,600 RPM.
The blade uses specially formulated industrial chromium micrograin carbide teeth and Silver-Copper-Silver tri-metal brazing. This construction is designed to reduce cutting-edge abrasion, support cut quality and service life, and help the carbide teeth withstand the stress and impact associated with non-ferrous and composite cutting.
ORANGE SHIELD® non-stick coating helps prevent overheating, corrosion, rust, residue buildup, and excessive blade drag. Laser-cut heat-expansion slots, patented dynamic balancing, the visible tensioning ring on the 10-inch blade, and precision mirror-finish sharpening support controlled heavy-duty cutting in aluminum, brass, copper, PVC, and other compatible non-ferrous stock.
Technical Specifications
Series 284.7 · SKU 284.700.10
- CMT Orange Tools
- Industrial thin-stock non-ferrous metal and PVC circular saw blade
- 284.700.10
- 284.7 — Industrial Thin Stock Non-Ferrous Metal, PVC Blades
- 10 in
- 5/8 in
- 96
- TCG — Triple Chip Grind
- 0.126 in
- 0.098 in
- +6°
- 7,600 RPM
- Cutting Material: Industrial chromium micrograin carbide · Brazing: Silver-Copper-Silver tri-metal brazing · Coating: Non-stick ORANGE SHIELD® · Plate Feature: Laser-cut heat-expansion slots · Stability Features: Patented dynamic balancing and tensioning ring · Sharpening: Precision mirror finish · less than 0.25 μm Rmax
- For compatible radial-arm saws, miter saws, table saws, and special saws accepting a 10-inch blade with a 5/8-inch arbor. Confirm arbor and flange fit, blade rotation, guarding, secure clamping of extrusions or PVC stock, chip control, and a speed not exceeding 7,600 RPM.
Best Fit Applications
Thin-Walled Aluminum Extrusions
Thick-Walled Non-Ferrous Extrusions
Brass & Copper
PVC Profiles & Sheet
Radial, Miter, Table & Special Saws
Product Highlights
Thin-Stock TCG Geometry
The 96-tooth triple-chip grind is intended for heavy-duty cutting, with excellent performance on thin-walled extrusions and good performance on thicker extrusions.
Industrial Carbide Stability System
Chromium micrograin carbide, tri-metal brazing, ORANGE SHIELD® coating, heat-expansion slots, dynamic balancing, a tensioning ring, and mirror sharpening support stable operation.
Compatibility & Installation Notes
Confirm exact Item Code 284.700.10, a compatible 10-inch saw-blade capacity, and a clean 5/8-inch arbor with properly matched flanges. Verify blade rotation, guarding, throat-plate clearance, secure clamping and support of extrusions or PVC stock, chip control, and controlled feed before use. Never exceed 7,600 RPM. Do not substitute the 12-inch 284.720.12 variant or specifications from another non-ferrous blade family.
Heavy-Duty Thin-Stock Non-Ferrous Cutting in a Verified 10-Inch Format
CMT 284.700.10 combines a 10-inch diameter, 5/8-inch bore, 96-tooth TCG geometry, 0.126-inch kerf, 0.098-inch plate, a positive 6° hook angle, and industrial chromium micrograin carbide teeth.
ORANGE SHIELD® coating, tri-metal brazing, laser-cut heat-expansion slots, patented dynamic balancing, a tensioning ring, and precision mirror-finish sharpening complete the verified Series 284.7 configuration.
