Exact 12-Inch 84T Variant
Item Code 223.084.12 combines a 12-inch diameter, 1-inch bore, 84 MTCG teeth, 0.126-inch kerf, 0.098-inch plate, 0° hook angle, and a 6,400 RPM maximum.
CMT Orange Tools 12" × 1" 84-Tooth Solid Surface Saw Blade
CA$999.99
In stock
SKU
223.084.12
Product Type
Industrial solid-surface circular saw blade
Family / Series
CMT 223 Industrial Solid Surface
Blade Diameter
12 inches
Bore Diameter
1 inch
Tooth Count / Grind
84 teeth · MTCG geometry
Kerf / Plate
0.126-inch kerf · 0.098-inch plate
Hook / Max Speed
0° hook angle · 6,400 RPM maximum
Cutting Material
Industrial SINTERHIP high-density carbide
Applications
Solid surface,thin plastic,phenolic,plexiglass,vinyl,laminate flooring,and plywood
Industrial
Solid Surface Saw Blade
Solid Surface Blade
CMT 223.084.12 is the 12-inch imperial variant in the CMT 223 industrial solid-surface circular-saw-blade family. It combines a 1-inch bore, 84-tooth MTCG geometry, 0.126-inch kerf, 0.098-inch plate thickness, a 0° hook angle, industrial SINTERHIP high-density carbide teeth, ORANGE SHIELD® coating, and a 6,400 RPM maximum for heavy-duty cutting and smooth finishing in solid-surface and compatible plastic materials.
12 inBlade Diameter (D)
1 inBore Diameter (B)
84TTooth Count (Z)
MTCGTooth Geometry (β)
Solid Surface Blade
An industrial 12-inch circular saw blade with 84 MTCG teeth, SINTERHIP high-density carbide, silver-alloy brazing, a laser-cut 44 HRC steel plate, laser-cut sound-dampening slots, a tensioning ring, precision sharpening, and CMT non-stick ORANGE SHIELD® coating.
CMT Orange ToolsSINTERHIP Carbide84T MTCGSKU 223.084.12
For compatible radial-arm saws, miter saws, table saws, and special saws accepting a 12-inch blade with a 1-inch arbor. Confirm arbor and flange fit, guarding, workpiece support, rotation, and a machine speed that does not exceed the blade’s 6,400 RPM maximum.
Main Product Description
CMT 223.084.12 is the 12-inch imperial item in the official 223 industrial solid-surface circular-saw-blade family. The verified CMT catalog record specifies a 12-inch diameter, 1-inch bore, 84 teeth, MTCG tooth geometry, 0.126-inch kerf, 0.098-inch plate thickness, and a 0° hook angle. CMT’s current blade-speed chart assigns a 6,400 RPM maximum to 12-inch blades.
The Series 223 construction uses a laser-cut 44 HRC high-quality steel plate, laser-cut sound-dampening slots, silver-alloy brazing, and SINTERHIP high-density carbide. CMT describes the hot-isostatic pressing process as producing a fully consolidated, low-porosity carbide structure intended to improve cutting life and reduce breakage risk.
ORANGE SHIELD® non-stick PTFE coating helps protect against corrosion and rust while reducing residue buildup, overheating, and blade drag. A visible tensioning ring on blades 250 mm and larger supports stability and concentric rotation, while precision CNC sharpening provides controlled edge geometry for heavy-duty cutting and smooth finishing without melting.
Technical Specifications
Series 223 · SKU 223.084.12
- CMT Orange Tools
- Industrial solid-surface circular saw blade
- 223.084.12
- 223 — Industrial Solid Surface Circular Saw Blades
- 12 in
- 1 in
- 84
- MTCG
- 0.126 in
- 0.098 in
- 0°
- 6,400 RPM
- Cutting Material: Industrial SINTERHIP high-density carbide · Brazing: Silver-alloy brazing · Coating: Non-stick ORANGE SHIELD® PTFE · Plate Body: Laser-cut 44 HRC high-quality steel · Sound Control: Laser-cut sound-dampening slots · Stability Feature: Tensioning ring · Sharpening: Precision multi-axis CNC sharpening · less than 0.35 μm Rmax
- For compatible radial-arm saws, miter saws, table saws, and special saws accepting a 12-inch blade with a 1-inch arbor. Confirm arbor and flange fit, guarding, workpiece support, rotation, and a machine speed that does not exceed the blade’s 6,400 RPM maximum.
Best Fit Applications
Solid-Surface Materials
Thin Plastic
Phenolic Materials
Plexiglass & Vinyl
Laminate Flooring & Plywood
Product Highlights
MTCG Solid-Surface Geometry
The 84-tooth MTCG configuration is designed for heavy-duty cutting and smooth finishing without melting in solid-surface and compatible plastic materials.
Industrial Stability System
SINTERHIP carbide, silver brazing, ORANGE SHIELD® coating, sound-dampening slots, a laser-cut steel plate, and a tensioning ring support stable cutting.
Compatibility & Installation Notes
Confirm exact Item Code 223.084.12, a compatible 12-inch saw-blade capacity, and a clean 1-inch arbor with properly matched flanges. Verify blade rotation, guard and throat-plate clearance, stable support of solid-surface or plastic sheet material, and controlled feed before use. Never exceed 6,400 RPM, and do not substitute the metric 223.084.12M variant, which uses a different bore and item code.
Heavy-Duty Solid-Surface Cutting in a Verified 12-Inch Format
CMT 223.084.12 combines a 12-inch diameter, 1-inch bore, 84-tooth MTCG geometry, 0.126-inch kerf, 0.098-inch plate, a 0° hook angle, and industrial SINTERHIP high-density carbide teeth.
ORANGE SHIELD® coating, silver-alloy brazing, laser-cut sound-dampening slots, a 44 HRC steel plate, a tensioning ring, and precision CNC sharpening complete the verified Series 223 configuration.
