Exact 10-Inch 80T Variant
Item Code 225.672.10 combines a 10-inch diameter, 5/8-inch bore, 80 TCG teeth, 0.126-inch kerf, 0.098-inch plate, −6° hook angle, and a 7,600 RPM maximum.
CMT Orange Tools 10" × 5/8" 80-Tooth Non-Ferrous Metal, PVC & Melamine Saw Blade
CA$999.99
In stock
SKU
225.672.10
Product Type
Industrial non-ferrous metal,PVC and melamine circular saw blade
Family / Series
CMT 225 Industrial Non-Ferrous,PVC &Melamine
Blade Diameter
10 inches
Bore Diameter
5/8 inch
Tooth Count / Grind
80 teeth · TCG triple-chip grind
Kerf / Plate
0.126-inch kerf · 0.098-inch plate
Hook / Max Speed
−6° hook angle · 7,600 RPM maximum
Cutting System
Industrial chromium micrograin carbide · ORANGE CHROME®
Applications
Aluminum,brass,copper,PVC,melamine,and related non-ferrous materials
Industrial
Non-Ferrous & Panel Blade
Non-Ferrous Blade
CMT 225.672.10 is the exact 10-inch ORANGE CHROME® variant in the CMT 225 industrial non-ferrous-metal, PVC, and melamine circular-saw-blade family. It combines a 5/8-inch bore, 80-tooth TCG geometry, 0.126-inch kerf, 0.098-inch plate thickness, a −6° hook angle, industrial chromium micrograin carbide teeth, and a verified maximum speed of 7,600 RPM for compatible cutting of aluminum, brass, copper, PVC, and melamine materials.
10 inBlade Diameter (D)
5/8 inBore Diameter (B)
80TTooth Count (Z)
TCGTooth Geometry (β)
Non-Ferrous Blade
An industrial 10-inch circular saw blade with 80 TCG teeth, industrial chromium micrograin carbide, Silver-Copper-Silver tri-metal brazing, laser-cut heat-expansion slots, patented dynamic balancing, a tensioning ring, precision mirror-finish sharpening, and the exact-row ORANGE CHROME® coating.
CMT Orange ToolsChrome Carbide80T TCGSKU 225.672.10
For compatible saws accepting a 10-inch blade with a 5/8-inch arbor. Confirm arbor and flange fit, guard clearance, rotation, workpiece support and clamping, chip control, and a machine speed that does not exceed the blade’s verified 7,600 RPM rating.
Main Product Description
CMT 225.672.10 is the exact 10-inch item in the official Series 225 industrial non-ferrous-metal, PVC, and melamine circular-saw-blade family. The verified live variation row specifies a 10-inch diameter, 5/8-inch bore, 80 teeth, TCG tooth geometry, 0.126-inch kerf, 0.098-inch plate thickness, a −6° hook angle, ORANGE CHROME® coating, and a maximum permitted speed of 7,600 RPM.
The blade uses specially formulated industrial chromium micrograin carbide teeth and Silver-Copper-Silver tri-metal brazing. The carbide formulation is intended to reduce cutting-edge abrasion and support cut quality and service life, while the brazing system helps the teeth withstand operating stress and impact.
ORANGE CHROME® is a thin electrolytically deposited chromium coating that increases wear resistance and resilience against corrosion and rust. Laser-cut heat-expansion slots, patented dynamic balancing, a visible tensioning ring on the 10-inch plate, and precision mirror-finish sharpening support stable cutting in aluminum, brass, copper, PVC, melamine, and related non-ferrous or panel materials.
Technical Specifications
Series 225 · SKU 225.672.10
- CMT Orange Tools
- Industrial non-ferrous metal, PVC and melamine circular saw blade
- 225.672.10
- 225 — Industrial Non-Ferrous Metal, PVC & Melamine Circular Saw Blades
- 10 in
- 5/8 in
- 80
- TCG — Triple Chip Grind
- 0.126 in
- 0.098 in
- −6°
- 7,600 RPM
- Cutting Material: Industrial chromium micrograin carbide · Brazing: Silver-Copper-Silver tri-metal brazing · Coating: ORANGE CHROME® · Plate Feature: Laser-cut heat-expansion slots · Stability Features: Patented dynamic balancing and tensioning ring · Sharpening: Precision mirror finish · less than 0.25 μm Rmax
- For compatible saws accepting a 10-inch blade with a 5/8-inch arbor. Confirm arbor and flange fit, guard clearance, rotation, workpiece support and clamping, chip control, and a machine speed that does not exceed the blade’s verified 7,600 RPM rating.
Best Fit Applications
Aluminum Extrusions
Brass & Copper
PVC Profiles & Sheet
Melamine Panels
Compatible 10-Inch Saw Setups
Product Highlights
TCG Non-Ferrous Geometry
The 80-tooth triple-chip grind and negative hook angle support controlled cutting in aluminum, brass, copper, PVC, melamine, and related materials.
ORANGE CHROME® Stability System
Chrome coating, chromium micrograin carbide, tri-metal brazing, heat-expansion slots, dynamic balancing, a tensioning ring, and mirror sharpening support stable operation.
Compatibility & Installation Notes
Confirm exact Item Code 225.672.10, a compatible 10-inch saw-blade capacity, and a clean 5/8-inch arbor with properly matched flanges. Verify blade rotation, guard and throat-plate clearance, secure clamping and support of non-ferrous or panel stock, and controlled feed before use. Never exceed 7,600 RPM. The exact CMT row identifies this item as 80T TCG with ORANGE CHROME®; do not substitute specifications from another Series 225 variant.
Controlled Non-Ferrous and Panel Cutting in a Verified 10-Inch Format
CMT 225.672.10 combines a 10-inch diameter, 5/8-inch bore, 80-tooth TCG geometry, 0.126-inch kerf, 0.098-inch plate, a −6° hook angle, and industrial chromium micrograin carbide teeth.
ORANGE CHROME® coating, tri-metal brazing, laser-cut heat-expansion slots, patented dynamic balancing, a tensioning ring, and precision mirror-finish sharpening complete the verified Series 225 configuration.
