Exact 10-Inch 40T Variant
Item Code 213.040.10 combines a 10-inch diameter, 5/8-inch bore, 40 teeth, 0.126-inch kerf, and a verified 7,600 RPM maximum.
CMT Orange Tools 10" × 5/8" 40-Tooth General Purpose Saw Blade
CA$999.99
In stock
SKU
213.040.10
Product Type
Industrial general-purpose circular saw blade
Family / Series
CMT 213 Industrial General Purpose
Blade Diameter
10 inches
Bore Diameter
5/8 inch
Tooth Count
40 teeth
Tooth Geometry
ATB 20°
Kerf / Plate
0.126-inch kerf · 0.100-inch plate
Hook / Max Speed
18° hook angle · 7,600 RPM maximum
Cutting System
Industrial chromium micrograin carbide · ORANGE SHIELD® coating
Industrial GP
General Purpose Saw Blade
Industrial GP Blade
CMT 213.040.10 is the exact 10-inch industrial general-purpose circular saw blade in the CMT 213 family. It combines a 5/8-inch bore, 40-tooth ATB 20° geometry, 0.126-inch kerf, 0.100-inch plate thickness, 18° positive hook angle, industrial chromium micrograin carbide teeth, ORANGE SHIELD® coating, and a verified maximum speed of 7,600 RPM for compatible general-purpose cutting in softwood, hardwood, and plywood.
10 inBlade Diameter (D)
5/8 inBore Diameter (B)
40TTooth Count (Z)
ATB 20°Tooth Geometry (β)
Industrial GP Blade
An industrial 10-inch general-purpose circular saw blade with 40 ATB teeth, industrial chromium micrograin carbide, Silver-Copper-Silver tri-metal brazing, laser-cut heat-expansion slots, a tensioning ring, precision mirror-finish sharpening, and CMT non-stick ORANGE SHIELD® coating.
CMT Orange ToolsIndustrial Carbide10-Inch BladeSKU 213.040.10
For compatible saws accepting a 10-inch blade with a 5/8-inch arbor. Confirm arbor fit, flange condition, guard clearance, rotation, workholding, and a machine speed that does not exceed the blade’s verified 7,600 RPM rating.
Main Product Description
CMT 213.040.10 is the exact 10-inch variant in the official 213 industrial general-purpose circular-saw-blade family. The verified item row specifies a 10-inch diameter, 5/8-inch bore, 40 teeth, ATB 20° tooth geometry, 0.126-inch kerf, 0.100-inch plate thickness, 18° hook angle, and a maximum permitted speed of 7,600 RPM.
CMT equips the family with specially formulated industrial chromium micrograin carbide teeth and Silver-Copper-Silver tri-metal brazing. Laser-cut heat-expansion slots help accommodate operating heat, while the visible tensioning ring on the 10-inch blade supports stability and concentric rotation.
The non-stick ORANGE SHIELD® coating is specified to resist overheating, corrosion, rust, and resin buildup while reducing blade drag. Precision mirror-finish sharpening on multi-axis CNC equipment produces controlled edge angles with less than 0.25 μm Rmax edge roughness for clean general-purpose cutting in softwood, hardwood, and plywood.
Technical Specifications
Series 213 · SKU 213.040.10
- CMT Orange Tools
- Industrial general-purpose circular saw blade
- 213.040.10
- 213 — Industrial General Purpose Circular Saw Blades
- 10 in
- 5/8 in
- 40
- ATB 20°
- 0.126 in
- 0.100 in
- 18°
- 7,600 RPM
- Cutting Material: Industrial chromium micrograin carbide · Brazing: Silver-Copper-Silver tri-metal brazing · Coating: Non-stick ORANGE SHIELD® · Plate Features: Laser-cut heat-expansion slots and tensioning ring · Balancing: CMT patented dynamic balancing · Sharpening: Precision mirror finish · less than 0.25 μm Rmax
- For compatible saws accepting a 10-inch blade with a 5/8-inch arbor. Confirm arbor fit, flange condition, guard clearance, rotation, workholding, and a machine speed that does not exceed the blade’s verified 7,600 RPM rating.
Best Fit Applications
General-Purpose Wood Cutting
Softwood Cutting
Hardwood Cutting
Plywood Cutting
Compatible 10-Inch Saw Setups
Product Highlights
Industrial Carbide Tooth System
Chromium micrograin carbide teeth, ATB 20° geometry, and tri-metal brazing support clean cutting and resistance to cutting-edge abrasion.
Coated and Stabilized Plate
ORANGE SHIELD® coating, laser-cut heat-expansion slots, patented dynamic balancing, and a tensioning ring support controlled general-purpose cutting.
Compatibility & Installation Notes
Confirm exact Item Code 213.040.10, a compatible 10-inch saw-blade capacity, and a clean 5/8-inch arbor with properly matched flanges. Verify blade rotation, guard and throat-plate clearance, secure workholding, fence or guide alignment, and machine condition before use. Never exceed the blade’s verified 7,600 RPM maximum, and do not select the blade by the 213 family number alone.
Industrial General-Purpose Cutting in a Verified 10-Inch Format
CMT 213.040.10 combines a 10-inch diameter, 5/8-inch bore, 40-tooth ATB 20° geometry, 0.126-inch kerf, 0.100-inch plate, 18° hook angle, and industrial chromium micrograin carbide teeth.
ORANGE SHIELD® coating, tri-metal brazing, heat-expansion slots, dynamic balancing, a tensioning ring, and precision mirror-finish sharpening complete the verified 213-series configuration.
