Working geometry
The tooth pattern and cutting width determine how the blade engages the workpiece.
CMT 285.072.14M – Saw Blade 350xb30+PH02x72T ATB 3.5 Kerf
CA$198.60
In stock
SKU
285.072.14M
Product Type
Industrial Crosscut Saw Blade
Tool Material
Carbide Tipped
Cutting Diameter
350 mm
Bore Diameter
30 mm
Kerf
3.5 mm
Plate Thickness
2.5 mm
Teeth
72
Hook Angle
15 degrees
Tooth Grind
ATB 10
Industrial Crosscut Saw Blade
CMT Utensili
285.072.14M
Designed to make straight saw cuts.
350 mmCutting Diameter
30 mmBore Diameter
285Series
CMT UtensiliBrand
Industrial Crosscut Saw Blade
Carbide tips form the working edges, supported by the tool body.
Carbide TippedSKU 285.072.14M
Match the 30 mm bore and all locating features to the machine mounting.
Main Product Description
This CMT Utensili industrial crosscut saw blade is designed to make straight saw cuts.
The tooth pattern and cutting width determine how the blade engages the workpiece. Match the diameter and bore to the saw before fitting the blade. Carbide tips form the working edges, supported by the tool body.
The blade diameter is 350 mm, with 72 teeth. The 30 mm bore must match the arbor and the complete mounting arrangement. Its nominal kerf is 3.5 mm.
Technical Specifications
285.072.14M · Industrial Crosscut Saw Blade
- CMT Utensili
- 285.072.14M
- Industrial Crosscut Saw Blade
- 285
- Carbide Tipped
- 350 mm
- 30 mm
- 3.5 mm
- 2.5 mm
- 72
- 15 degrees
- ATB 10
Tool Configuration
crosscutting
Product Highlights
Cutting material
Carbide tips form the working edges, supported by the tool body.
This version
The blade diameter is 350 mm, with 72 teeth. The 30 mm bore must match the arbor and the complete mounting arrangement. Its nominal kerf is 3.5 mm.
Compatibility & Installation Notes
Match the tool and holder to the machine, workpiece and intended operation before use. Match blade diameter, bore, speed rating and guarding to the machine; maximum RPM is a limit, not a recommended cutting speed.
Industrial Crosscut Saw Blade
CMT Utensili 285.072.14M is designed to make straight saw cuts.
The tooth pattern and cutting width determine how the blade engages the workpiece. Match the diameter and bore to the saw before fitting the blade. Carbide tips form the working edges, supported by the tool body.
The blade diameter is 350 mm, with 72 teeth. The 30 mm bore must match the arbor and the complete mounting arrangement. Its nominal kerf is 3.5 mm. Match the 30 mm bore and all locating features to the machine mounting.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
