Exact 10-Inch 60T Variant
Item Code 221.060.10 combines a 10-inch diameter, 5/8-inch bore, 60 TCG teeth, 0.126-inch kerf, 0.087-inch plate, and a verified 7,600 RPM maximum.
CMT Orange Tools 10" × 5/8" 60-Tooth Cabinetshop Heavy-Duty Multi-Purpose Saw Blade
CA$999.99
In stock
SKU
221.060.10
Product Type
Industrial cabinetshop heavy-duty multi-purpose circular saw blade
Family / Series
CMT 221 Industrial Heavy-Duty Multi-Purpose
Blade Diameter
10 inches
Bore Diameter
5/8 inch
Tooth Count / Grind
60 teeth · TCG triple-chip grind
Kerf / Plate
0.126-inch kerf · 0.087-inch plate
Hook / Max Speed
10° hook angle · 7,600 RPM maximum
Cutting Material
Industrial chromium micrograin carbide
Applications
Heavy-duty crosscuts in laminated panels,chipboard,MDF,plywood,and hardwood
Industrial Cabinetshop
Heavy-Duty Multi-Purpose Blade
Cabinetshop Blade
CMT 221.060.10 is the exact 10-inch variant in the CMT 221 industrial heavy-duty multi-purpose circular-saw-blade family. It combines a 5/8-inch bore, 60-tooth TCG geometry, 0.126-inch kerf, 0.087-inch plate thickness, 10° hook angle, industrial chromium micrograin carbide teeth, ORANGE SHIELD® coating, and a verified maximum speed of 7,600 RPM for controlled crosscutting in compatible cabinetshop saw setups.
10 inBlade Diameter (D)
5/8 inBore Diameter (B)
60TTooth Count (Z)
TCGTooth Geometry (β)
Cabinetshop Blade
An industrial heavy-duty multi-purpose 10-inch circular saw blade with 60 TCG teeth, industrial chromium micrograin carbide, Silver-Copper-Silver tri-metal brazing, laser-cut heat-expansion slots, a tensioning ring, precision mirror-finish sharpening, and CMT non-stick ORANGE SHIELD® coating.
CMT Orange ToolsIndustrial Carbide60T TCGSKU 221.060.10
For compatible miter saws, radial-arm saws, stationary table saws, and vertical panel saws accepting a 10-inch blade with a 5/8-inch arbor. Confirm arbor and flange fit, guard clearance, workholding, feed control, and a machine speed that does not exceed 7,600 RPM.
Main Product Description
CMT 221.060.10 is the exact 10-inch item in the official 221 industrial heavy-duty multi-purpose circular-saw-blade family. The verified variation row specifies a 10-inch diameter, 5/8-inch bore, 60 teeth, TCG tooth geometry, 0.126-inch kerf, 0.087-inch plate thickness, 10° hook angle, and a maximum permitted speed of 7,600 RPM.
The blade uses specially formulated industrial chromium micrograin carbide teeth and Silver-Copper-Silver tri-metal brazing. This construction is designed to reduce cutting-edge abrasion and help the carbide withstand the stress and impact encountered when cutting harder woods and composite panel materials.
CMT’s non-stick ORANGE SHIELD® coating helps limit overheating, corrosion, rust, resin buildup, and blade drag. Laser-cut heat-expansion slots accommodate operating heat, while patented dynamic balancing, the visible tensioning ring, and precision mirror-finish sharpening support stable, controlled crosscuts in cabinetshop materials and compatible saw machinery.
Technical Specifications
Series 221 · SKU 221.060.10
- CMT Orange Tools
- Industrial cabinetshop heavy-duty multi-purpose circular saw blade
- 221.060.10
- 221 — Industrial Heavy-Duty Multi-Purpose Circular Saw Blades
- 10 in
- 5/8 in
- 60
- TCG — Triple Chip Grind
- 0.126 in
- 0.087 in
- 10°
- 7,600 RPM
- Cutting Material: Industrial chromium micrograin carbide · Brazing: Silver-Copper-Silver tri-metal brazing · Coating: Non-stick ORANGE SHIELD® · Plate Feature: Laser-cut heat-expansion slots · Stability Features: Patented dynamic balancing and tensioning ring · Sharpening: Precision mirror finish · less than 0.25 μm Rmax
- For compatible miter saws, radial-arm saws, stationary table saws, and vertical panel saws accepting a 10-inch blade with a 5/8-inch arbor. Confirm arbor and flange fit, guard clearance, workholding, feed control, and a machine speed that does not exceed 7,600 RPM.
Best Fit Applications
Heavy-Duty Crosscutting
Single-Sided Laminated Panels
Chipboard, MDF & OSB
Hardwood, Softwood & Plywood
Miter, Radial, Table & Panel Saws
Product Highlights
TCG Cabinetshop Geometry
The 60-tooth triple-chip grind and controlled 10° hook angle suit heavy-duty crosscuts and clean finishing in laminated and composite cabinetshop materials.
Industrial Carbide Stability System
Chromium micrograin carbide, tri-metal brazing, ORANGE SHIELD® coating, heat-expansion slots, dynamic balancing, and a tensioning ring support stable cutting.
Compatibility & Installation Notes
Confirm exact Item Code 221.060.10, a compatible 10-inch saw-blade capacity, and a clean 5/8-inch arbor with properly matched flanges. Verify rotation, guard and throat-plate clearance, secure workholding, fence or guide alignment, and controlled feed before use. Never exceed the verified 7,600 RPM maximum, and do not select the blade by the 221 family number alone.
Heavy-Duty Cabinetshop Crosscutting in a Verified 10-Inch Format
CMT 221.060.10 combines a 10-inch diameter, 5/8-inch bore, 60-tooth TCG geometry, 0.126-inch kerf, 0.087-inch plate, 10° hook angle, and industrial chromium micrograin carbide teeth.
ORANGE SHIELD® coating, tri-metal brazing, laser-cut heat-expansion slots, patented dynamic balancing, a tensioning ring, and precision mirror-finish sharpening complete the verified Series 221 configuration.
