CMT Industrial Cabinetshop Heavy-Duty Multi-Purpose Circular Saw Blade 10" x 5/8" Bore, 60T TCG
Industrial Cabinetshop
Heavy-Duty Multi-Purpose Blade
CMT 221.060.10 is the exact 10-inch variant in the CMT 221 industrial heavy-duty multi-purpose circular-saw-blade family. It combines a 5/8-inch bore, 60-tooth TCG geometry, 0.126-inch kerf, 0.087-inch plate thickness, 10° hook angle, industrial chromium micrograin carbide teeth, ORANGE SHIELD® coating, and a verified maximum speed of 7,600 RPM for controlled crosscutting in compatible cabinetshop saw setups.
Main Product Description
CMT 221.060.10 is the exact 10-inch item in the official 221 industrial heavy-duty multi-purpose circular-saw-blade family. The verified variation row specifies a 10-inch diameter, 5/8-inch bore, 60 teeth, TCG tooth geometry, 0.126-inch kerf, 0.087-inch plate thickness, 10° hook angle, and a maximum permitted speed of 7,600 RPM.
The blade uses specially formulated industrial chromium micrograin carbide teeth and Silver-Copper-Silver tri-metal brazing. This construction is designed to reduce cutting-edge abrasion and help the carbide withstand the stress and impact encountered when cutting harder woods and composite panel materials.
CMT’s non-stick ORANGE SHIELD® coating helps limit overheating, corrosion, rust, resin buildup, and blade drag. Laser-cut heat-expansion slots accommodate operating heat, while patented dynamic balancing, the visible tensioning ring, and precision mirror-finish sharpening support stable, controlled crosscuts in cabinetshop materials and compatible saw machinery.
Best Fit Applications
Product Highlights
Exact 10-Inch 60T Variant
Item Code 221.060.10 combines a 10-inch diameter, 5/8-inch bore, 60 TCG teeth, 0.126-inch kerf, 0.087-inch plate, and a verified 7,600 RPM maximum.
TCG Cabinetshop Geometry
The 60-tooth triple-chip grind and controlled 10° hook angle suit heavy-duty crosscuts and clean finishing in laminated and composite cabinetshop materials.
Industrial Carbide Stability System
Chromium micrograin carbide, tri-metal brazing, ORANGE SHIELD® coating, heat-expansion slots, dynamic balancing, and a tensioning ring support stable cutting.
Compatibility & Installation Notes
Confirm exact Item Code 221.060.10, a compatible 10-inch saw-blade capacity, and a clean 5/8-inch arbor with properly matched flanges. Verify rotation, guard and throat-plate clearance, secure workholding, fence or guide alignment, and controlled feed before use. Never exceed the verified 7,600 RPM maximum, and do not select the blade by the 221 family number alone.
Heavy-Duty Cabinetshop Crosscutting in a Verified 10-Inch Format
CMT 221.060.10 combines a 10-inch diameter, 5/8-inch bore, 60-tooth TCG geometry, 0.126-inch kerf, 0.087-inch plate, 10° hook angle, and industrial chromium micrograin carbide teeth.
ORANGE SHIELD® coating, tri-metal brazing, laser-cut heat-expansion slots, patented dynamic balancing, a tensioning ring, and precision mirror-finish sharpening complete the verified Series 221 configuration.
