Working geometry
The pointed profile forms angled sides as it cuts.
CMT 815.690.11 – 90-Degree V-Groove Router Bit – 3/4 in Diameter
CA$29.80
In stock
SKU
815.690.11
Product Type
90-Degree V-Groove Router Bit
Tool Material
Carbide Tipped
Cutting Diameter
3/4 in
Cutting Length
5/8 in
Shank Diameter
1/2 in
Overall Length
2-1/2 in
V Profile Depth I1
3/8 in
Flutes
2
Included Angle
90 degrees
Rotation
Right Hand
90-Degree V-Groove Router Bit
CMT Utensili
815.690.11
Designed to cut V-shaped grooves and fine routed details.
3/4 inCutting Diameter
5/8 inCutting Length
1/2 inShank Diameter
2-1/2 inOverall Length
90-Degree V-Groove Router Bit
Carbide tips form the working edges, supported by the tool body.
Carbide TippedRight HandSKU 815.690.11
Choose a holder or collet for the 1/2 in shank and check the available tool clearance.
Main Product Description
This CMT Utensili 90-degree V-groove router bit is designed to cut V-shaped grooves and fine routed details. It is suitable for wood panels.
The pointed profile forms angled sides as it cuts. The depth of the pass changes the width of the resulting groove. Carbide tips form the working edges, supported by the tool body.
The 3/4 in cutting diameter and 5/8 in cutting length define the working section of this version. Its 1/2 in shank fits a holder or collet matched to that diameter.
Technical Specifications
815.690.11 · 90-Degree V-Groove Router Bit
- CMT Utensili
- 815.690.11
- 90-Degree V-Groove Router Bit
- 815
- Carbide Tipped
- 3/4 in
- 5/8 in
- 1/2 in
- 2-1/2 in
- 3/8 in
- 2
- 90 degrees
- Right Hand
Tool Configuration
V-grooving
lettering
45-degree chamfering
Product Highlights
Cutting material
Carbide tips form the working edges, supported by the tool body.
This version
The 3/4 in cutting diameter and 5/8 in cutting length define the working section of this version. Its 1/2 in shank fits a holder or collet matched to that diameter.
Compatibility & Installation Notes
Match the tool and holder to the machine, workpiece and intended operation before use.
90-Degree V-Groove Router Bit
CMT Utensili 815.690.11 is designed to cut V-shaped grooves and fine routed details. It is suitable for wood panels.
The pointed profile forms angled sides as it cuts. The depth of the pass changes the width of the resulting groove. Carbide tips form the working edges, supported by the tool body.
The 3/4 in cutting diameter and 5/8 in cutting length define the working section of this version. Its 1/2 in shank fits a holder or collet matched to that diameter.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
