Working geometry
Upcut and downcut sections work toward the middle of the material.
Amana Tool Compression Spiral Router Bit — 1/8 in dia, compression, Spektra nACo
CA$160.00
In stock
SKU
46180-K
Product Class
Router Bit
Product Type
Compression Spiral Router Bit
Manufacturer Part Number
46180-K
Cutting Diameter (D)
1/8 in
Cutting Height (B)
13/16 in
Shank Diameter
1/8 in
Overall Length (L)
2-1/2 in
Upcut Length
7/32 in
Cutting Material
Solid Carbide
Flutes
2
Cut Direction
compression
Coating
Spektra nACo
Compression Spiral Router Bit
Amana Tool
46180-K
Designed to route panel edges with opposing cutting directions.
1/8 inCutting Diameter (D)
13/16 inCutting Height (B)
1/8 inShank Diameter
2-1/2 inOverall Length (L)
Compression Spiral Router Bit
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
Router BitSKU 46180-K
Choose a holder or collet for the 1/8 in shank and check the available tool clearance.
Main Product Description
This Amana Tool compression spiral router bit is designed to route panel edges with opposing cutting directions.
Upcut and downcut sections work toward the middle of the material. With the transition positioned within the panel, the geometry helps support both faces during the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 1/8 in cutting diameter and 13/16 in cutting length define the working section of this version. Its 1/8 in shank fits a holder or collet matched to that diameter. The upcut section is 7/32 in long; position the transition within the material.
Technical Specifications
46180-K · Compression Spiral Router Bit
- Amana Tool
- 46180-K
- Router Bit
- Compression Spiral Router Bit
- Amana Tool Compression Spiral Router Bit
- 46180-K
- 1/8 in
- 13/16 in
- 1/8 in
- 2-1/2 in
- 7/32 in
- Solid Carbide
- 2
- compression
- Spektra nACo
Product Configuration
compression routing
Product Highlights
Cutting material
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
This version
The 1/8 in cutting diameter and 13/16 in cutting length define the working section of this version. Its 1/8 in shank fits a holder or collet matched to that diameter. The upcut section is 7/32 in long; position the transition within the material.
Compatibility & Installation Notes
Match the part number, mounting dimensions and machine configuration before ordering. Follow the tool and machine manufacturer’s installation and operating instructions.
Compression Spiral Router Bit
Amana Tool 46180-K is designed to route panel edges with opposing cutting directions.
Upcut and downcut sections work toward the middle of the material. With the transition positioned within the panel, the geometry helps support both faces during the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 1/8 in cutting diameter and 13/16 in cutting length define the working section of this version. Its 1/8 in shank fits a holder or collet matched to that diameter. The upcut section is 7/32 in long; position the transition within the material.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
