Two Usable Cutting Edges
Rotate the indexable insert after the first edge becomes worn to place the second cutting edge into service.
Amana Tool Solid Carbide V-Groove Insert MDF Replacement Knife, 28 x 12 x 1.5mm
CA$999.99
Out of stock
SKU
RCK-352
Product Type
Solid Carbide V-Groove MDF Replacement Cutter
Family / Category
MDF V-Groove,Miter Fold &Signmaking Insert CNC Replacement Cutters
Dimensions
28 × 12 × 1.5mm
Compatible Tool Nos.
RC-1100,RC-1103,RC-1105
Cutting Material
Solid carbide
Indexing
Two usable cutting edges per insert
Applications
Miter folds,signmaking,and lettering
Material Groups
MDF/HDF,composites,laminate,melamine,sign board,wood,and veneered plywood
Solid Carbide V-Groove
MDF Replacement Cutter
Replacement Cutter
Amana Tool RCK-352 is a 28 × 12 × 1.5mm solid-carbide V-groove replacement cutter for Amana Tool RC-1100, RC-1103, and RC-1105 CNC insert tool bodies. The indexable design provides two usable cutting edges for miter-fold, signmaking, and lettering applications.
28 mmLength
12 mmWidth
1.5 mmThickness
Two UsesIndexable Insert
Replacement Cutter
A solid-carbide replacement cutting component for Amana Tool V-groove CNC insert tooling. Its 28 × 12 × 1.5mm dimensions and exact Tool No. identify the correct service component for the compatible RC-series tool bodies.
Amana ToolSolid CarbideV-Groove SystemSKU RCK-352
Officially specified for Amana Tool RC-1100, RC-1103, and RC-1105. The cutter can be rotated when one edge becomes worn, providing a second usable cutting edge within the same insert body.
Main Product Description
Amana Tool RCK-352 is the exact solid-carbide V-groove MDF replacement cutter measuring 28 × 12 × 1.5mm. The dedicated manufacturer page specifies this component for Tool Nos. RC-1100, RC-1103, and RC-1105.
The indexable insert design provides two uses from each cutter. When the active edge becomes worn, the insert can be rotated to present the second cutting edge. The system is intended for miter folds, signmaking, and lettering.
Manufacturer-listed workpiece groups include MDF/HDF, composites, composite decking, foam, laminate, melamine, sign board, solid surface, veneered plywood, wood, and other published materials. Selected metals and carbon fibre are listed for engraving only.
Technical Specifications
V-Groove MDF Replacement Cutter · RCK-352
- Amana Tool
- Solid Carbide V-Groove MDF Replacement Cutter
- RCK-352
- Insert CNC Replacement Cutters
- Solid Carbide MDF V-Groove, Miter Fold & Signmaking Insert CNC Replacement Cutters
- 28 × 12 × 1.5mm
- Solid Carbide
- Two cutting edges per insert
- Miter folds, signmaking & lettering
- 28 mm
- 12 mm
- 1.5 mm
- Miter Folds · Signmaking & Lettering · MDF / HDF & Sign Board
- Officially specified for Amana Tool RC-1100, RC-1103, and RC-1105. The cutter can be rotated when one edge becomes worn, providing a second usable cutting edge within the same insert body.
Best Fit Applications
Miter Folds
Signmaking & Lettering
MDF / HDF & Sign Board
Laminate, Melamine & Composites
Wood & Veneered Plywood
Product Highlights
Exact RC-Series Fit
The official specification identifies RCK-352 for Amana Tool RC-1100, RC-1103, and RC-1105 CNC insert tool bodies.
Replaceable Solid Carbide
Insert tooling supports quick, precise cutter replacement and uses a solid-carbide cutting component instead of replacing the complete brazed router bit.
Compatibility & Installation Notes
Use RCK-352 only with Amana Tool RC-1100, RC-1103, or RC-1105. Before operating an insert tool, confirm the set screw is tightened firmly. When replacing a worn cutter, clean the tool and remove dust from the seating area before installing the replacement. Use suitable CNC workholding to reduce the possibility of material movement.
Verified Replacement Fit for Three Amana Tool V-Groove Bodies
RCK-352 combines a 28 × 12 × 1.5mm solid-carbide format with two usable cutting edges for V-groove insert applications.
Its verified fit is limited to RC-1100, RC-1103, and RC-1105, supporting miter-fold, signmaking, and lettering work across the manufacturer-listed material groups.
