Vortex Tool Spoilboard Cutter Replacement Screw
Spoilboard Cutter
Replacement Screw
Genuine Vortex replacement hardware for compatible spoilboard cutter bodies and related insert-tooling systems. SKU 67116 is a 5.0 mm × 0.8 flat-head Torx screw with a verified 0.246-inch (6.24 mm) length and T20 service interface.
Main Product Description
The Vortex Tool 67116 is the replacement retaining screw used across compatible spoilboard cutter and insert-tooling assemblies. Vortex lists it for bodies 7025, 7030, 7040, 8030, 8040, 8045, and 8300, allowing the correct manufacturer hardware to be restored during insert service.
Official Vortex kit records show 67116 screws securing 13273 solid-carbide spoilboard inserts in the 7025 through 8045 cutter families. The same screw is identified with insert 13276 in the 8300/8310 V-groove tooling system, making exact body and insert verification essential before installation.
The verified screw specification is 5.0 mm × 0.8 with a 0.246-inch (6.24 mm) length and a T20 Torx drive. Vortex recommends the 7001W T20 driver wrench for service, with the T20TH torque wrench available for controlled tightening where required by the tooling procedure.
Best Fit Applications
Product Highlights
Verified Vortex Compatibility
Designed for the listed Vortex spoilboard and insert-tooling bodies rather than as a universal replacement fastener.
Exact 5.0 mm × 0.8 Specification
The official Vortex drawing identifies the thread and 0.246-inch (6.24 mm) screw length for correct service selection.
T20 Service Interface
Compatible with the Vortex 7001W T20 driver and T20TH torque wrench for matched tooling maintenance.
Compatibility & Installation Notes
This is non-cutting replacement hardware, not a universal screw. Confirm the exact Vortex cutter body and insert before installation. Use only clean, undamaged 67116 screws with intact T20 drive features and threads. Clean the insert pocket, seating surfaces, and threaded bore; fully seat the correct insert; start the screw by hand to avoid cross-threading; and tighten evenly with the approved T20 service tool and the correct torque procedure for the assembly. Do not substitute a screw with a different head shape, thread, pitch, length, or drive size.
Matched Hardware for Reliable Insert Service
Vortex Tool 67116 provides the verified 5.0 mm × 0.8 flat-head T20 retaining hardware used across compatible spoilboard cutter and V-groove insert-tooling systems.
Correct body identification, insert selection, clean seating surfaces, undamaged threads, matched T20 tooling, and controlled tightening are essential to retaining the insert securely without damaging the screw or cutter body.
