Working geometry
Use the cutter for the final pass that establishes the finished edge.
Vortex 1340L – 2-Flute Downcut Finishing Spiral Router Bit – 3/8 in Diameter – Left Hand
CA$101.60
In stock
SKU
1340L
Product Type
2-Flute Downcut Finishing Spiral Router Bit
Tool Material
Solid Carbide
Cutting Diameter
3/8 in
Cutting Length
1-1/4 in
Shank Diameter
3/8 in
Overall Length
3 in
Flutes
2
Cut Direction
Downcut
Rotation
Left Hand
2-Flute Downcut Finishing Spiral Router Bit
Vortex
1340L
Designed to finish routed edges and contours.
3/8 inCutting Diameter
1-1/4 inCutting Length
3/8 inShank Diameter
3 inOverall Length
2-Flute Downcut Finishing Spiral Router Bit
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
Solid CarbideDowncutLeft HandSKU 1340L
Choose a holder or collet for the 3/8 in shank and check the available tool clearance.
Main Product Description
This Vortex 2-flute downcut finishing spiral router bit is designed to finish routed edges and contours. It is suitable for wood.
Use the cutter for the final pass that establishes the finished edge. A consistent allowance along the toolpath helps keep the cut even. The downcut geometry shears toward the workpiece, helping support the top edge during the pass. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 3/8 in cutting diameter and 1-1/4 in cutting length define the working section of this version. Its 3/8 in shank fits a holder or collet matched to that diameter. This is a left-hand tool; it must be used with the matching spindle rotation.
Technical Specifications
1340L · 2-Flute Downcut Finishing Spiral Router Bit
- Vortex
- 1340L
- 2-Flute Downcut Finishing Spiral Router Bit
- 1300
- Solid Carbide
- 3/8 in
- 1-1/4 in
- 3/8 in
- 3 in
- 2
- Downcut
- Left Hand
Tool Configuration
dado routing
groove routing
through cutting
Product Highlights
Cutting material
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
This version
The 3/8 in cutting diameter and 1-1/4 in cutting length define the working section of this version. Its 3/8 in shank fits a holder or collet matched to that diameter. This is a left-hand tool; it must be used with the matching spindle rotation.
Compatibility & Installation Notes
Ramp into the cut; do not plunge straight down with downcut tooling. Provide suitable chip clearance and workholding.
2-Flute Downcut Finishing Spiral Router Bit
Vortex 1340L is designed to finish routed edges and contours. It is suitable for wood.
Use the cutter for the final pass that establishes the finished edge. A consistent allowance along the toolpath helps keep the cut even. The downcut geometry shears toward the workpiece, helping support the top edge during the pass. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 3/8 in cutting diameter and 1-1/4 in cutting length define the working section of this version. Its 3/8 in shank fits a holder or collet matched to that diameter. This is a left-hand tool; it must be used with the matching spindle rotation.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
