Working geometry
The cutting section follows the programmed path or guide to form the required shape.
Royce Ayr 2-Flute Upcut Spiral Router Bit - 3/8" Dia x 1-1/8" Cut
CA$91.30
In stock
SKU
R52-32821
Product Type
2-Flute Upcut Spiral Router Bit
Diameter
3/8 in (9.52 mm)
Cutting Edge
1-1/8 in (28.575 mm)
Shank
3/8 in (9.52 mm)
Overall Length
3 in (76.2 mm)
Rotation
RH / Right Hand
Cutting Geometry
2-Flute Upcut Spiral
Construction
Solid Carbide / HW
Application
Solid Wood Routing, Wood-Composite Routing, Compatible Plastic Routing, Grooving & Slotting, CNC Component Machining
2-Flute Upcut Spiral
Router Bit
General-Purpose Upcut Spiral
Designed to route grooves, profiles and pockets.
D=3/8 in9.52 mm Diameter
CE=1-1/8 in28.575 mm Cutting Edge
Sh=3/8 in9.52 mm Shank
OAL=3 in76.2 mm Overall Length
Upcut Spiral Router Bit
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
HW / Solid Carbide2 Flutes2-Flute Upcut SpiralSKU R52-32821
Choose a holder or collet for the 3/8 in shank and check the available tool clearance.
Main Product Description
This Royce Ayr solid carbide upcut spiral router bit is designed to route grooves, profiles and pockets. It is suitable for solid wood, wood composites and selected plastics.
The cutting section follows the programmed path or guide to form the required shape. Choose the entry method and depth of cut to suit the tool’s end geometry. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 3/8 in cutting diameter and 1-1/8 in cutting length define the working section of this version. Its 3/8 in shank fits a holder or collet matched to that diameter.
Technical Specifications
Upcut Spiral Router Bit · R52-32821
- Royce Ayr
- 2-Flute Upcut Spiral Router Bit
- R52-32821
- General Purpose Upcut Spiral
- 0.3750 in / 3/8 in (9.52 mm)
- 1.125 in / 1-1/8 in (28.575 mm)
- 0.375 in / 3/8 in (9.52 mm)
- 3.000 in / 3 in (76.2 mm)
- 2
- Upcut Spiral
- RH / Right Hand
- None
- Material Compatibility: Solid Wood, Wood Composites, MDF, Core Panels, and Compatible Plastics · Machine Interface: CNC Routers with Precision 3/8-Inch Collets · Construction: Solid-Carbide Substrate
- Designed for compatible CNC routers using a precision 3/8-inch (9.52 mm) collet or approved toolholding system with sufficient clearance for the 3-inch overall length.
Best Fit Applications
Solid Wood Routing
Wood-Composite Routing
Compatible Plastic Routing
Grooving & Slotting
CNC Component Machining
Product Highlights
Cutting material
The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
This version
The 3/8 in cutting diameter and 1-1/8 in cutting length define the working section of this version. Its 3/8 in shank fits a holder or collet matched to that diameter.
Compatibility & Installation Notes
Confirm toolholding for the shank size 0.375" and right-hand spindle operation. Secure the workpiece against lift from the upcut action. Plastic suitability is conditional; confirm the exact grade and cutting conditions.
Controlled General-Purpose Upcut Routing
Royce Ayr R52-32821 is designed to route grooves, profiles and pockets. It is suitable for solid wood, wood composites and selected plastics.
The cutting section follows the programmed path or guide to form the required shape. Choose the entry method and depth of cut to suit the tool’s end geometry. The upcut spiral lifts chips out of the cut. The solid-carbide cutting section provides rigidity and wear resistance at the working edge.
The 3/8 in cutting diameter and 1-1/8 in cutting length define the working section of this version. Its 3/8 in shank fits a holder or collet matched to that diameter.
For help selecting this version, share your machine model, workpiece material and intended operation with Titan.
