Downcut Finishing Direction
Downcut flute direction supports controlled finishing engagement in compatible plastics, composites, and solid wood.
Royce Ayr 2-Flute Straight Solid Carbide Router Bit - 1/2" Diameter x 1" Cut
CA$274.15
In stock
SKU
R60-22307
Product Type
2 Flute Straight General Purpose Router Bit
Diameter
1/2 in (12.7 mm)
Cutting Edge
1 in (25.4 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3 in (76.2 mm)
Rotation
Right-Hand (RH)
Article Number
R60-22307
Application
Solid Wood,MDF,Slotting,Dadoing,Profiling
3-Flute Downcut Low Helix
Finisher Router Bit
Downcut Low Helix Finisher
Solid-carbide downcut low-helix finisher for routing plastics and composites and for finish passes in solid wood. Its 1/2-inch cutting diameter, 2-1/8-inch cutting edge, 1/2-inch shank, three-flute geometry, and 4-1/2-inch overall length provide extended finishing reach in compatible CNC systems.
D=1/2 in12.7 mm Diameter
CE=2-1/8 in53.975 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=4-1/2 in114.3 mm Overall Length
Downcut Low Helix Finisher
This three-flute solid-carbide tool combines downcut flute direction with low-helix finishing geometry for controlled routing in plastics, composites, and solid-wood finishing applications.
Solid Carbide / HW3 FlutesDowncut Low HelixSKU R60-22307
Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system with sufficient clearance for the 4-1/2-inch overall length.
Main Product Description
The Royce Ayr 3-Flute Downcut Low Helix Finisher Router Bit R60-22307 belongs to Royce Ayr's 3-Flute Downcut Low Helix Finisher series. The manufacturer specifies this series for routing plastics and composites and for finish passes in solid wood.
Its downcut flute direction and low-helix geometry support controlled material engagement during finishing operations. The three-flute format is suited to compatible CNC routing when spindle speed, feed rate, and chip load are correctly matched.
The 0.5000-inch cutting diameter, 2.125-inch cutting edge, 0.500-inch shank, and 4.500-inch overall length require rigid, low-runout toolholding and adequate machine clearance. Before machining, verify collet condition, tool projection, spindle speed, feed rate, depth per pass, workholding, and chip extraction for the material being processed.
Technical Specifications
Downcut Low Helix Finisher R60-22307
- Royce Ayr
- 3-Flute Downcut Low Helix Finisher Router Bit
- R60-22307
- 3-Flute Downcut Low Helix Finisher
- HW / Solid Carbide
- 0.5000 in / 1/2 in (12.7 mm)
- 2.125 in / 2-1/8 in (53.975 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 4.500 in / 4-1/2 in (114.3 mm)
- 3
- Downcut Low Helix Finisher
- HW / Solid Carbide
- Material Compatibility: Plastics, Composites, and Finish Passes in Solid Wood · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system with sufficient clearance for the 4-1/2-inch overall length.
Best Fit Applications
Plastic Finishing
Composite Routing
Solid-Wood Finish Passes
Downcut Profile Machining
Extended-Reach Finishing
Product Highlights
Low-Helix Geometry
Low-helix geometry is intended for finish-routing applications where controlled cutting action is required.
Extended 2-1/8-Inch Cutting Edge
The 2-1/8-inch cutting edge and 4-1/2-inch overall length provide added reach for compatible CNC finishing operations.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/2-inch (12.7 mm) shank and provides sufficient clearance for the 4-1/2-inch (114.3 mm) overall length. Use rigid, low-runout toolholding, minimize unsupported projection where possible, and establish suitable spindle speed, feed rate, depth per pass, workholding, and chip extraction for the material being machined.
Extend Downcut Finishing Reach
The Royce Ayr 3-Flute Downcut Low Helix Finisher Router Bit R60-22307 provides a solid-carbide solution for routing plastics and composites and for finish passes in solid wood.
Its 1/2-inch diameter and shank, 2-1/8-inch cutting edge, three-flute downcut low-helix geometry, and 4-1/2-inch overall length suit compatible CNC systems when the tool is correctly held and operated within appropriate machining parameters.
