Downcut Finishing Direction
Downcut flute direction supports controlled finishing engagement in compatible plastics, composites, and solid wood.
Royce Ayr 2-Flute Straight Carbide Router Bit - 1/2" Diameter x 1" Cut
CA$214.80
In stock
SKU
R60-22312
Product Type
2 Flute Straight General Purpose Router Bit
Diameter
1/2 in (12.7 mm)
Cutting Edge
1 in (25.4 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3 in (76.2 mm)
Rotation
Right-Hand (RH)
Article Number
R60-22312
Application
Solid Wood,MDF,Slotting,Dadoing,Profiling
3-Flute Downcut Low Helix
Finisher Router Bit
Downcut Low Helix Finisher
Solid-carbide downcut low-helix finisher for routing plastics and composites and for finish passes in solid wood. Its 1/2-inch cutting diameter, 1-5/8-inch cutting edge, 1/2-inch shank, three-flute geometry, and 4-inch overall length provide extended finishing reach in compatible CNC systems.
D=1/2 in12.7 mm Diameter
CE=1-5/8 in41.275 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=4 in101.6 mm Overall Length
Downcut Low Helix Finisher
This three-flute solid-carbide tool combines downcut flute direction with low-helix finishing geometry for controlled routing in plastics, composites, and solid-wood finishing applications.
Solid Carbide / HW3 FlutesDowncut Low HelixSKU R60-22312
Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system with sufficient clearance for the 4-inch overall length.
Main Product Description
The Royce Ayr 3-Flute Downcut Low Helix Finisher Router Bit R60-22312 belongs to Royce Ayr's 3-Flute Downcut Low Helix Finisher series. The manufacturer specifies this series for routing plastics and composites and for finish passes in solid wood.
Its downcut flute direction and low-helix geometry support controlled material engagement during finishing operations. The three-flute format is suited to compatible CNC routing when spindle speed, feed rate, and chip load are correctly matched.
The 0.5000-inch cutting diameter, 1.625-inch cutting edge, 0.500-inch shank, and 4.000-inch overall length require rigid, low-runout toolholding and adequate machine clearance. Before machining, verify collet condition, right-hand spindle rotation, tool projection, spindle speed, feed rate, depth per pass, workholding, and chip extraction.
Technical Specifications
Downcut Low Helix Finisher R60-22312
- Royce Ayr
- 3-Flute Downcut Low Helix Finisher Router Bit
- R60-22312
- 3-Flute Downcut Low Helix Finisher
- HW / Solid Carbide
- 0.5000 in / 1/2 in (12.7 mm)
- 1.625 in / 1-5/8 in (41.275 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 4.000 in / 4 in (101.6 mm)
- 3
- Downcut Low Helix Finisher
- RH / Right Hand
- Coating: None · Construction: HW / Solid Carbide · Material Compatibility: Plastics, Composites, and Finish Passes in Solid Wood · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system with sufficient clearance for the 4-inch overall length.
Best Fit Applications
Plastic Finishing
Composite Routing
Solid-Wood Finish Passes
Downcut Profile Machining
Extended-Reach Finishing
Product Highlights
Low-Helix Geometry
Low-helix geometry is intended for finish-routing applications where controlled cutting action is required.
Extended 1-5/8-Inch Cutting Edge
The 1-5/8-inch cutting edge and 4-inch overall length provide added reach for compatible CNC finishing operations.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/2-inch (12.7 mm) shank and provides sufficient clearance for the 4-inch (101.6 mm) overall length. Use rigid, low-runout toolholding, minimize unsupported projection where possible, verify right-hand rotation, and establish suitable spindle speed, feed rate, depth per pass, workholding, and chip extraction for the material being machined.
Extend Downcut Finishing Capability
The Royce Ayr 3-Flute Downcut Low Helix Finisher Router Bit R60-22312 provides a solid-carbide solution for routing plastics and composites and for finish passes in solid wood.
Its 1/2-inch diameter and shank, 1-5/8-inch cutting edge, three-flute downcut low-helix geometry, and 4-inch overall length suit compatible CNC systems when the tool is correctly held and operated within appropriate machining parameters.
