Leitz Premium Industrial Panel Saw Blade D400x4.4x60 72T FZ/TR L470080116
Premium FZ/TR Panel
Saw Blade
Industrial carbide-tipped circular saw blade designed for high-output panel sizing. Its 400 mm diameter, 4.4 mm kerf, 72-tooth FZ/TR geometry, and 60 mm bore with dual pin holes support stable tracking and clean edge quality in laminated panels, MDF, particleboard, and veneered sheet goods.
Main Product Description
The Leitz Premium FZ/TR Panel Saw Blade L470080116 is engineered for high-capacity panel sizing where clean, consistent edges are required across demanding sheet materials. Its 400 mm diameter and 4.4 mm kerf provide a rigid cutting platform for bilaminate panels, melamine-faced board, MDF, particleboard, and veneered core materials.
The 72-tooth flat/trapezoidal FZ/TR grind alternates cutting action across the tooth sequence to balance material removal and support reduced chipping in coated panels. Premium industrial carbide tips provide wear resistance and help maintain cutting accuracy through repeated production cycles.
A 3.2 mm steel plate core, precision balancing, expansion-slot geometry, and vibration-damping features help control lateral movement, heat growth, and operating noise. The 60 mm bore with two drive pin holes provides positive engagement on compatible industrial panel-sizing equipment.
Best Fit Applications
Product Highlights
FZ/TR Triple-Chip Geometry
Alternating flat and trapezoidal teeth distribute cutting loads to support clean edges in coated and engineered panels.
Vibration-Controlled Plate
Precision plate tensioning, expansion slots, and damping features help reduce lateral harmonics during deep production cuts.
Premium Micro-Grain HW
Industrial carbide tips support thermal stability and extended cutting-edge retention in high-volume panel sizing.
Compatibility & Installation Notes
Disconnect and isolate the machine before installation. Confirm that the arbor, collars, guarding, and drive-pin configuration accept a 400 mm blade with a 60 mm bore and dual pin holes. Never exceed the maximum RPM marked on the blade. Verify correct rotation, scoring-unit alignment, material hold-down pressure, feed direction, dust extraction, and secure clamping before production.
Improve Industrial Panel-Sizing Quality
The Leitz Premium FZ/TR Panel Saw Blade L470080116 is built for panel processors, architectural millwork manufacturers, and high-output cabinet shops requiring stable, accurate sizing of challenging sheet goods. Its 400 mm diameter, 4.4 mm kerf, 60 mm bore with dual pin holes, and 72-tooth FZ/TR profile support consistent cutting on compatible machinery.
A precision-balanced steel core and premium carbide cutting tips help reduce vibration, control spindle loading, preserve edge quality, and extend sharpening intervals across demanding multi-shift production schedules.
