Four-Wing Z4 Geometry
The verified C173 design uses four cutting wings in a dedicated T-slot cutter format for compatible routing operations.
Klein HW Z4 T-Slot Cutter, 41 mm Diameter x 2 mm Cutting Width, 8 mm Shank
CA$999.99
In stock
SKU
C173.020.R
Product Type
HW Z4 T-Slot Cutter
Family
Klein C173
Cutter Diameter
41 mm
Cutting Width
2 mm
Shank / Overall
8 mm shank · 43 mm overall length
Cutting Geometry
Four-wing Z4 T-slot profile
Cutting Material
HW carbide
Machine Fit
Hand router machines and router tables
Materials
Softwood,hardwood,aluminium,plastic,plexiglass,and PVC
HW Z4
T-Slot Cutter
HW T-Slot Cutter
A Klein C173 four-wing HW carbide T-slot cutter with a 41 mm cutter diameter, 2 mm cutting width, 8 mm shank, and 43 mm overall length. The exact C173.020.R Item is listed for compatible hand router machines and router tables working softwood, hardwood, aluminium, plastic, plexiglass, and PVC.
41 mmCutter Diameter (D)
2 mmCutting Width (B)
8 mmShank Diameter (S)
Z4Four-Wing Geometry
HW T-Slot Cutter
The C173 family uses a four-wing T-slot cutter format for compatible routing in plastic materials, aluminium, softwood, and hardwood. This exact Item combines the 41 mm diameter body with a 2 mm cutting width.
HW CarbideT-Slot Profile8 mm ShankSKU C173.020.R
For compatible hand router machines and router tables using an 8 mm collet. Confirm collet condition, cutter clearance, machine guarding, workholding, intended slot dimensions, and the applicable machine and tool speed limits before production use.
Main Product Description
Klein C173.020.R is the exact 2 mm cutting-width variant in the C173 family of HW Z4 T-slot cutters. The official Item row specifies an 8 mm shank, 41 mm cutter diameter, 2 mm cutting width, and 43 mm overall length.
The four-wing cutter geometry is intended to produce a narrow T-slot profile in compatible material when used in a properly matched hand router or router table. The official family page identifies plastic material and aluminium as primary uses and also lists softwood, hardwood, plexiglass, and PVC among supported workpiece groups.
Correct 8 mm collet fit, cutter clearance, machine guarding, workholding, entry strategy, feed direction, and compliance with the machine and tool speed ratings are essential. Verify that the 41 mm cutter body and 2 mm cutting width suit the intended T-slot geometry before machining.
Technical Specifications
Family C173 · SKU C173.020.R
- Klein
- HW Four-Wing T-Slot Cutter
- C173.020.R
- SISTEMI Hand Router Tooling
- C173
- 8 mm
- 41 mm
- 2 mm
- 43 mm
- 4
- HW Carbide
- T-Slot
- Machine Type: Hand Router Machine / Router Table · Supported Materials: Softwood, Hardwood, Aluminium, Plastic, Plexiglass, PVC
- For compatible hand router machines and router tables using an 8 mm collet. Confirm collet condition, cutter clearance, machine guarding, workholding, intended slot dimensions, and the applicable machine and tool speed limits before production use.
Best Fit Applications
Plastic / Plexiglass / PVC
Aluminium T-Slot Routing
Softwood Slot Profiles
Hardwood Slot Profiles
Hand Router & Router Table Work
Product Highlights
41 mm x 2 mm Exact Format
The C173.020.R Item pairs a 41 mm cutter diameter with a narrow 2 mm cutting width and 43 mm overall length.
Hand Router and Table Fit
Official machinery guidance lists both hand router machines and router tables when equipped with a compatible 8 mm collet and adequate clearance.
Compatibility & Installation Notes
Confirm the exact C173.020.R Item code rather than selecting by the C173 family alone. Use a clean, compatible 8 mm collet and verify that the router, table opening, guard, fence, and workholding provide safe clearance for the 41 mm cutter body. Confirm the required 2 mm slot width, tool projection, feed direction, material support, and the applicable machine and tool speed limits before use.
Compact Z4 T-Slot Geometry
Klein C173.020.R combines a 41 mm cutter diameter, 2 mm cutting width, 8 mm shank, 43 mm overall length, and four-wing HW carbide geometry for compatible T-slot routing.
Correct collet fit, machine clearance, guarding, workholding, feed direction, slot geometry, and adherence to the machine and tool speed ratings are essential to safe, consistent production use.
