CNC machining centres, hand routers, and router tables
Klein · SISTEMI Hand Router Tooling
HW Z2 Finger-Grip Router Bit
A Klein G116 HW carbide finger-grip router bit with a 1/2-inch
(12.7 mm) shank, 19 mm primary profile diameter, 10 mm secondary
diameter, 19 mm primary working height, 14 mm secondary working
height, and 57 mm overall length. The exact G116.190.R Item uses
a 4.8 mm and 2.5 mm dual-radius profile for integrated pulls in
compatible drawer and cabinet-door edges.
19 mmPrimary Diameter (D1)
R4.8 / R2.5Dual-Radius Profile
1/2 inShank · 12.7 mm
Z2Two Cutting Edges
Main Product Description
Klein G116.190.R is the exact 1/2-inch-shank Item in the
E116–G116 family of HW Z2 finger-grip router bits. The official
Item row specifies a 12.7 mm (1/2-inch) shank, 19 mm primary
diameter, 10 mm secondary diameter, 19 mm primary working
height, 14 mm secondary working height, 57 mm overall length,
4.8 mm primary radius, and 2.5 mm secondary radius.
The family is designed to create integrated pulls in drawer
fronts and cabinet doors, providing a positive grip and an
easy edge for the fingers. Klein notes that these profiles can
remove substantial material and recommends multiple passes
when the required stock removal is large.
Verified workpiece groups include softwood, hardwood, and
chipboard. Official machine guidance lists CNC machining
centres, hand router machines, and router tables. Correct
collet fit, cutter clearance, guarding, workholding, and
progressive cutting depth are essential for controlled
profile routing.
Best Fit Applications
Integrated Cabinet-Door Pulls
Drawer-Front Finger Grips
R4.8 / R2.5 Profiling
Softwood, Hardwood & Chipboard
CNC, Hand Router & Table
Product Highlights
01
Compact Finger-Pull Profile
The verified 19 mm primary diameter and 10 mm secondary
diameter create the compact profile assigned to G116.190.R.
02
R4.8 / R2.5 Geometry
The exact Item combines 4.8 mm and 2.5 mm radii with
19 mm and 14 mm working heights to form the specified grip.
03
HW Carbide Z2 Cutting
Two HW carbide cutting edges support compatible profiling
in softwood, hardwood, and chipboard across the listed machines.
!
Compatibility & Installation Notes
Confirm the exact G116.190.R Item code. This G-series version
uses a 1/2-inch (12.7 mm) shank; the corresponding E116.190.R
variant uses a 12 mm shank. Use a clean compatible collet and
verify cutter clearance, projection, guarding, fence or CNC
toolpath, workholding, feed direction, and applicable machine
and tool speed limits. Use multiple passes when removing large
amounts of material.
Compact Cabinet Finger-Grip Profiling
Klein G116.190.R combines a 19 mm primary diameter, 10 mm
secondary diameter, R4.8 / R2.5 dual-radius profile, 19 mm
and 14 mm working heights, Z2 HW carbide geometry, and a
1/2-inch shank.
Correct shank identification, collet fit, clearance, guarding,
pass depth, workholding, feed direction, and machine parameters
are essential to controlled material removal and consistent
profile quality.
